ThinkPad X220

This page gives an overview of the ThinkPad X220.

Features

  • One of the following processors:
    • Intel® Core™ i3-2310M (2.1GHz, 3MB L3 cache)
    • Intel® Core™ i5-2410M (2.3GHz, 3MB L3 cache)
    • Intel® Core™ i5-2410M (2.3GHz, 3MB L3 cache)
    • Intel® Core™ i5-2520M (2.5GHz, 3MB L3 cache)
    • Intel® Core™ i5-2540M (2.6GHz, 3MB L3 cache)
    • Intel® Core™ i7-2620M (2.7GHz, 4MB L3 cache)
    • Intel® Core™ i7-2640M (2.8GHz, 4MB L3 cache)
  • Up to 8GB PC3-10600 DDR3 memory at 1333MHz
    • 16GB (2x8GB) PC3-14900 at 1866MHz possible
  • Intel HD Graphics 3000
  • One of the following TFT displays:
    • 12.5' TFT display with 1366x768 resolution with LED backlight
    • 12.5' extra bright wide-viewing IPS TFT display with 1366x768 resolution with LED backlight
  • 2.5' × 7mm hard drive bay with one of the following hard drives:
    • 4GB SSD SATA
    • Intel 80GB Micro SSD SATA
    • 128GB SSD SATA
    • Intel 160GB SSD SATA
    • 160GB 7200RPM SATA
    • 250GB 5400RPM SATA
    • 250GB 7200RPM SATA (with limited OPAL FDE technology)
    • 320GB 5400RPM SATA
    • 320GB 7200RPM SATA
  • MiniPCI Express slot 1 with zero or one of the following:
  • MiniPCI Express slot 2 with zero or one of the following:
    • Qualcomm Gobi 3000 WWAN
    • LeadCore TD-SCDMA (LC5730D) WWAN
    • Ericsson HSPA + (F5521gw) WWAN
    • Huawei EV-DO (EM660) WWAN
    • mSATA drive
  • Three USB ports (of which one is USB 3.0 on the i7 model)
  • 720p HD Integrated camera
  • DisplayPort (supports audio)
  • Stereo digital microphones
  • Stereo speakers
  • Combined headphone and microphone jack
  • UltraNav (Trackpoint and Buttonless Touchpad)
  • Integrated Fingerprint Reader (UPEK)
  • Comes with 65W AC Adapter
  • Supports ThinkPad UltraBase Series 3, ThinkPad Mini Dock Series 3, etc.

Lenovo X220 Slots Factory

  • The interface on the X220 motherboard that connects to the LCD cable. The interface that connects to the palm rest. Here’s mini PCI-E slot. X220 motherboard Gigabit Ethernet port. The only blue USB 3.0 port of the laptop. Both sides of the X220 motherboard use black insulation tape. Uncover a corner of the black insulation tape.
  • Lenovo ThinkPad X220 Intel Core i7, SSD. High Speed SSD 128GB, The Lenovo ThinkPad X220 combines a new backlit keyboard with a fast third-generation Core processor and long-lasting batteries.
  • The ThinkPad X series is a line of laptop computers and convertible tablets produced by Lenovo.It was initially produced by IBM until 2005. IBM announced the ThinkPad X series (initially the X20) in September 2000 with the intention of providing “workers on the move with a better experience in extra-thin and extra-light mobile computing.”.

Lenovo ThinkPad X220 Core i5 8GB RAM 128GB SSD WebCamera Wifi,Bluetooth Windows 10. Get High Performance With 8GB Ram and SSD. With backlit keyboard and a fast third generation Core processor and long lasting battery making it a great ultraportable. Lenovo's ThinkPad X200 series has a long history of combining lightweight portability, epic battery life, and uncompromising performance. The 12.5-inch, $1,299 ThinkPad X220 offers a couple of new.

Upgrade

Resources

Lenovo X220 Slots

Notes

  • The CPU speed will be throttled back to 800MHz if the machine is run on the 65W AC adapter with no battery installed. To avoid this throttling
    • run on a 90W AC adapter, or
    • install a battery pack.
  • It's possible to use a mSATA SSD within the second MiniPCI Express slot.
  • On booting:
    • The X220 cannot/will not boot GPT disks using Legacy BIOS, you must setup UEFI.
    • The X220 will not boot /efi/*/*.efi unless 'signed'(?) into BIOS, you have to copy it to /efi/boot/bootx64.efi.
    • Disabling the BIOS setting 'USB UEFI BIOS Support' disables *all* USB booting, ie, both UEFI and legacy BIOS.
  • Maximum DDR3 speed depends on the BIOS version. BIOS versions up to 1.28 allow RAM speeds up to 1866MHz. BIOS versions 1.29 and above limit RAM to 1333MHz. Modified versions of BIOS available that remove this limitation.
  • The combined headphone/microphone jack is a 4-pin TRRS connector and is wired as per CTIA/AHJ standard (tip - left, ring1 - right, ring2 - ground, sleeve - mic). Which means, it is compatible with most modern cellphone headsets (including Apple); however, it is not compatible with older Nokia and Samsung headsets wired as OMTP.
